You are invited to apply for subsidized access to the following Technologies.

 Nanofabrication

CMC Microsystems is evaluating a new fabrication process developed in collaboration with Applied Nanotools (ANT) and Institut National d'Optique (INO).

About the Technology

  • The NanoSOI process is conducted on a thin SOI wafer.
  • The silicon and the deposited metal are patterned using e-beam lithography.
  • The buried oxide is isotropically etched to release the nano structures.

This process has under gone preliminary testing and is ready for further exploration by researchers involved in nanotechnology applications requiring the nano patterning of metal and silicon. Three different example applications of the NanoSOI process are:


 Nanobeam Resonator




 Photonics Crystal Bandgap



 Phase Retarder_imed.jpg

  THz Phase Retarder



Process Options

  • Silicon-On-Insulator: Two thickness options are available: 145 nm and 300 nm.
  • Metal: Two options are available: Aluminum and Chromium/Gold.
  • Process Flows: Based on the end goal of the process, 6 different flows are available. Please refer to the design manual for a description of the available options for the NanoSOI process.

For more information about the NanoSOI process, design size requirements, pricing, and related topics, please contact:

Dr. Imed Zine-El-Abidine, Senior Engineer, Micro/nanotechnology Fabrication,CMC Microsystems 613.530.4795, imed@cmc.ca

  Application Deadline January 10, 2010

Click here to Apply

Applications Also Being Accepted

CMC is always open to accepting applications for access to the following products and services.  Applications are due by the 10th day of each month so that peer review can be scheduled accordingly.

Topics include:

Click here to Apply.

Who Can Benefit

This peer-reviewed competition is intended for faculty and graduate students at a university in Canada who:

  • Are registered clients of CMC
  • Intend to develop a working proof-of-concept prototype within 9 months.
  • Are developing microsystems prototypes that integrate multiple technologies for applications in biomedical, environmental, or telecommunications.
